| Article number: | 0250016715 |
| Quantity in stock: | 1 |
THE SCENE VLT IS TAILOR-MADE TO FIT YOUR MODERN LIFE WITH ITS CASUAL STYLING AND DEMEANOR,
AND CREATED SPECIFICALLY FOR PEOPLE WHO WANT TO GO PLACES, NO SWEAT.
The Scene VLT is an award-winning, ultra-versatile, relaxed electric hybrid that gets around easily. With a flat bar and comfortable upright riding position, the Scene VLT replaces the need for a car in the city. With the Shimano STEPS motor, and 504Wh battery, the Scene VLT makes even the hilliest rides no sweat at all.
The nearly silent yet powerful Shimano STEPS drive system is integrated into the Scene VLT’s beautiful aluminum frame with a lower center of gravity for stress-free mounts and dismounts, and easy maneuverability.
| Electric System | |
| drive unit | Shimano STePS DU-EP600
|
| battery | Shimano BT-EN605
|
| External Charging | Shimano EC-E6002, 1.8A |
| Display | Shimano SC-EN500
|
| Sensor | Shimano EW-SS300 Sensor |
| Frameset | |
| Frame | Double Butted Alloy E-Bike Frame, Internal Cables |
| Fork | Aluminum w/ Light Mount, 12x100 TA, PS |
| Headset | Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40) |
| Drivetrain | |
| rear DERAILLEUR | Shimano CUES RD-U4020, 9sp, SGS |
| Cassette | Shimano CUES CS-LG300-9, 11-36T, 9sp |
| Chain | KMC eGlide, 9sp |
| Crankset | Shimano FC-EM600, 38T, 165mm |
| pedals | City Pedal, Kraton Traction Inlay |
| Shifter Rear | Shimano CUES SL-U4000-9R, 9sp |
| Components | |
| Grips | Dual Density Ergonomic Single Lock, 133mm Length |
| Handlebar | Norco Scene Aluminum, 660mm, 60mm Rise, 30Deg Backsweep |
| Stem | Norco Aluminum, 70mm (S/M) -80mm (M/L), 17deg Riser, 31.8 clamp |
| Seat Post | TranzX YSP18PLQ, 31.6mm, 100mm |
| Seat Post Clamp | Norco Alloy QR, 31.8mm ID |
| Saddle | Scene Comfort Saddle w/Elastomer Suspension, 225mm W x 269mm L |
| Front Brake | Tektro HD-M280 Auriga, 2-P, Resin Pads, Anti-Vibration |
| Front Brake Rotor | Tektro TR160-52, 160mm, 1.8mm Thickness , 6-bolt |
| Rear Brake | Tektro HD-M280 Auriga, 2-P, Resin Pads, Anti-Vibration |
| Rear Brake Rotor | Tektro TR160-52, 160mm, 1.8mm Thickness , 6-bolt |
| Brake Levers | Tektro HD-M280 Auriga |
| kICKSTAND | Center Mount Alloy, Black |
| Wheels | |
| Front Hub | Formula DC-221T, 15x100mm TA, 32h, 6-bolt |
| Rear Hub | Formula DC-142,12x142mm Boost, HG, 32h, 6-bolt |
| Spokes/Nipples | 13G Stainless Steel w/Brass Nipples 2.0MMX16MM - Black |
| Rims | Alloy DW Disc w/27mm ID, 32h |
| TireS | Kenda Kwick Seven5, 27.5 x 2.2", 30 TPI, Wire |
| Front Hub Skewer | Thru Axle, L125, M15x1.5 |
| Rear Hub Skewer | Thru Axle, L167, M12x12.75 (maxle) |
| weight | 20.1 kg / 44.3 lb |
GEOMETRY
| Frame Size: | S | M | L |
| Reach: | 355 | 365 | 375 |
| Stack: | 593 | 621 | 649 |
| Head Tube Angle: | 68.0 | ||
| Fork Offset: | 50 | ||
| Seat Tube Length: | 425 | 450 | 475 |
| Effective Seat Tube Angle: | 68.0 | ||
| Rear Centre Length: | 470 | ||
| Bottom Bracket Rise/Drop: | -67 | ||
| Bottom Bracket Height: | 285 | ||
| Horizontal Top Tube: | 595 | 616 | 637 |
| Wheel Base: | 1087 | 1108 | 1129 |
| Stand Over: | 415 | ||
| Head Tube Length: | 170 | 200 | 230 |
| Trail: | 88 | ||
| Recommended Seat Post Drop: | 100 | 120 | 120 |
| Maximum Post Insertion: | 250 | 250 | 300 |
| Stem Length: | 70 | 70 | 70 |
| Crank Length: | 170 | 170 | 170 |
| Tire Size: | 2.0"-2.35" | ||
| Water Bottle Compatible: | 750 mL | ||
The Scene VLT Fits Your Life from Norco Bicycles on Vimeo.
The Scene VLT is tailor-made to fit your modern life with its casual styling and demeanor, and created specifically for people who want to go places, no sweat.
| IMPORTANT:
This Norco bicycle can only be delivered to the Customer as fully assembled and tuned by a Norco dealer.
*Sorry, we cannot cover assembly charges which other Norco dealers will charge. Assembly, tune, and any furter tuneups are free of charge when when the bike is picked up at our store. |
